HEA

מבחר גדול של ברזל מקצועי מסוג HEA שחור ומגולוון משמש לבניית מבנים, סככות, מכונות שונות ועוד.



פריט

G
kg/m

h
mm

b
mm

tw
mm

tf
mm

r
mm

A
cm²

hi
mm

d
mm

HE 100 A 16.7 96 100 5.0 8.0 12 21.24 80 56
HE 120 A 19.9 114 120 5.0 8.0 12 25.34 98 74
HE 140 A 24.7 133 140 5.5 8.5 12 31.42 116 92
HE 160 A 30.4 152 160 6.0 9.0 15 38.77 134 104
HE 180 A 35.5 171 180 6.0 9.5 15 45.25 152 122
HE 200 A 42.3 190 200 6.5 10.0 18 53.83 170 134
HE 220 A 50.5 210 220 7.0 11.0 18 64.34 188 152
HE 240 A 60.3 230 240 7.5 12.0 21 76.84 206 164
HE 260 A 68.2 250 260 7.5 12.5 24 86.82 225 177
HE 280 A 76.4 270 280 8.0 13.0 24 97.26 244 196
HE 300 A 88.3 290 300 8.5 14.0 27 112.5 262 208
HE 320 A 97.6 310 300 9.0 15.5 27 124.4 279 225
HE 340 A 105 330 300 9.5 16.5 27 133.5 297 243
HE 360 A 112 350 300 10.0 17.5 27 142.8 315 261
HE 400 A 125 390 300 11.0 19.0 27 159.0 352 298
HE 450 A 140 440 300 11.5 21.0 27 178.0 398 344
HE 500 A 155 490 300 12.0 23.0 27 197.5 444 390
HE 550 A 166 540 300 12.5 24.0 27 211.8 492 438
HE 600 A 178 590 300 13.0 25.0 27 226.5 540 486
HE 650 A 190 640 300 13.5 26.0 27 241.6 588 534
HE 700 A 204 690 300 14.5 27.0 27 260.5 636 582
HE 800 A 224 790 300 15.0 28.0 30 285.8 734 674
HE 900 A 252 890 300 16.0 30.0 30 320.5 830 770
HE 1000 A 272 990 300 16.5 31.0 30 346.8 928 868
