HEB

מבחר גדול של ברזל מקצועי מסוג HEB שחור ומגולוון משמש לבניית מבנים, סככות, מכונות שונות ועוד.



פריט

G
kg/m

h
mm

b
mm

tw
mm

tf
mm

r
mm

A
cm²

hi
mm

d
mm

HE 100 B 20.4 100 100 6.0 10.0 12 26.04 80 56
HE 120 B 26.7 120 120 6.5 11.0 12 34.01 98 74
HE 140 B 33.7 140 140 7.0 12.0 12 42.96 116 92
HE 160 B 42.6 160 160 8.0 13.0 15 54.25 134 104
HE 180 B 51.2 180 180 8.5 14.0 15 65.25 152 122
HE 200 B 61.3 200 200 9.0 15.0 18 78.08 170 134
HE 220 B 71.5 220 220 9.5 16.0 18 91.04 188 152
HE 240 B 83.2 240 240 10.0 17.0 21 106.0 206 164
HE 260 B 93.0 260 260 10.0 17.5 24 118.4 225 177
HE 280 B 103 280 280 10.5 18.0 24 131.4 244 196
HE 300 B 117 300 300 11.0 19.0 27 149.1 262 208
HE 320 B 127 320 300 11.5 20.5 27 161.3 279 225
HE 340 B 134 340 300 12.0 21.5 27 170.9 297 243
HE 360 B 142 360 300 12.5 22.5 27 180.6 315 261
HE 400 B 155 400 300 13.5 24.0 27 197.8 352 298
HE 450 B 171 450 300 14.0 26.0 27 218.0 398 344
HE 500 B 187 500 300 14.5 28.0 27 238.6 444 390
HE 550 B 199 550 300 15.0 29.0 27 254.1 492 438
HE 600 B 212 600 300 15.5 30.0 27 270.0 540 486
HE 650 B 225 650 300 16.0 31.0 27 286.3 588 534
HE 700 B 241 700 300 17.0 32.0 27 306.4 636 582
HE 800 B 262 800 300 17.5 33.0 30 334.2 734 674
HE 900 B 291 900 300 18.5 35.0 30 371.3 830 770
HE 1000 B 314 1000 300 19.0 36.0 30 400.0 928 868
